Model |
Divyarath Garbage Vehicle |
Seating Capacity |
1 (only driver) |
Speed |
Max 25 Km/hr |
Max Climbing |
10% |
Turning Radius |
1.5 m |
Motor |
48 V 1000 W (70 mm magnet) |
Controller |
24 Tube 60 Amp |
Accelerator |
Throattle Two Wheeler Type (N/D/R) |
Steering |
Two Wheeler Type |
Max Travel |
80-100 km per charge |
Brake Range |
2<=M |
Carrying Capacity |
380 Kg * |
Kerb Weight ( With Battery) |
415 Kg* (As per design) |
Chassis |
C' Section Mold process Struction or Square Tubular pile * |
Body |
1 mm sheet metal with stamping process * |
Wheel Base |
2100 mm |
Wheel Track |
860 mm |
Tyre |
90/90-12 tubeless and tube; 3-75-12 tube tyre & 4.00-12 ( Heavy Duty )* |
Roof |
Fabric/ Metal |
Dimension L X W X H |
2610 X 1000 X 1780 mm |
Charger Input Voltage |
220 V 50 Hz |
Charger Capacity |
Lead Acid- 48V 15 Amp; Li-ion 48V 25 amp* |
Charger Voltage |
48/60 volt SMPS with auto cutoff |
Charging Time |
Lead Acid- 6-7 hr; Li-ion 2-3 Hrs * |
Power Consumption |
5 - 6 KW/h /100 KM |
Suspension |
Front : Hydraulic shocker with helicle spring;Rear : Leaf spring ( Heavy Duty) |
Rear Wheel Brake |
Hydraulic Brake |
Garbage container |
Chemical Treatment done and anti rust spray paint with two side intake and rear side outlet of collection * |
Container hydraulic |
1 Tonn capacity with electric button operation * |
|
Term and condition : All Star Marked(*) are made with special order |
