E-Scooter SUPER ECO S2

KEY FEATURES OF E-SCOOTER SUPER ECO S2
LOWER RUNNING COST – RS. 0.20/- PER KM ZERO EMISSION (POLLUTANT FREE) NOISE FREE RTO APPROVED IN 23 STATES LIGHT WEIGHT EASY DRIVE

---

---

MOTOR	German Bosch 60V ; 1200W Electrically limited 250 W
BATTERY	Lithium Ion 60V 26 Ah and (33 Ah optional)
CONTROLLER	16 Tube 45 Amp FOC ADVANCE
Range	70-80 Km Per charge / (100-105 optional)*
Brake	Disc On Both Wheel
Tyre Type	Tubeless
Console	Digital
CHARGER	4-6 HRS ON STANDERED 5A CHARGER

---

PASSENGER CAPACITY	2 PERSON
RANGE (LOADED) (KM)* in Ideal Condition	70-80 km/charge and (100-105 km per charge optional)
MAX. SPEED (KM/H)	UP TO 45KM/H
MIN. TURNING RADIUS(M)	1<=M
MAX. CLIMBING ABILITY (M)	UP TO 20%
BRAKING DISTANCE	2.8mm
MAX. LOADING WEIGHT (KGS)	150 KG

---

BRAKE SYSTEM	FRONT & REAR ;DISC BRAKE
MAX TORQUE	20 NM
FRONT SUSPENSION	Hydraulic Telescopic fork
REAR SUSPENSION	SPRING WITH HYDRAULIC CYLINDER SHOCK ABSORBER
Kerb Weight ( With Battery)	82kg
STARTING	Self-Start
WHEEL & TYRE	Front & Rear : 12inch Tubeless /alloy

---

OVERALL DIMENSION (MM)	1801X685X1150 mm
WHEEL BASE (MM)	1250 mm

---

CHASSIS	clad with steel metal
BODY	ABS/ Steel
WINDSHIELD	TOUGHENED LAMINATED SAFETY GLASS
FLOOR MAT	SKIPPROOF RUBBER
DASHROOF	Speedometer : Digital; Fuel Gauge: Digital; Console: Digital;

---

LIGHT	Headlight : Halogen; Tail Light : LED; Turn Signal Lamp : LED
DRLs	Yes
Boot Light	Yes
HORN	ELECTRIC HORN, 12V
DC TO DC CONVERTER	60 V TO 12 V
ELECTRICITY CONSUMPTION	1-1.5 UNITS
MOBILE CHARGER	Yes

---

GPS	YES (OPTIONAL)
Anti Theft Alarm	Yes
Navigation	Yes
DISTANCE ONLINE LOCKING VIA MOBILE APP (INDIA FIRST)	Optional
BMS	Yes
REGENERATIVE BREAKING SYSTEM	Yes
CROME FINISH STEEL GUARD	Yes
MOBILE APP SUPPORT	Yes(Optional)
DISTRESS ALARM SWITCH FOR WOMEN SAFETY (INDUSTRY FIRST)	Yes(Optional)
WIFI ENABLED	Yes(Optional)
KEY LESS PUSH BUTTON (INDIA FIRST)	CAN BE EMBEDDED
DISTRESS ALARM SWITCH FOR WOMEN SAFETY (INDUSTRY FIRST)	CAN BE EMBEDDED
ANDROID TOUCH SCREEN DISPLAY	CAN BE EMBEDDED
CAN BUS SUPPORT FOR ONLINE ANALYSIS (INDIA FIRST)	COMPATIBLE
Carry Hook	Yes
