E-Scooter SUPER ECO T1

KEY FEATURES OF E-SCOOTER SUPER ECO T1
MODEL NAME SUPER ECO T1 CARRYING CAPACITY 150 Kg DRIVING RANGE 70-80 Kms MIN. TURNING RADIUS 1<=M STANDARD COLOR As per choice MAX SPEED Max. 25 Km/ Per Hr. CLIMBING CAPACITY UP TO 8 % BRAKING DISTANCE 2.8mm

---

---

CONTROLLER	35 Amp 12 Tube FOC (ADVANCE)
MOTOR	60 V 1000W /ELECTRICALLY LIMITED TO 250 W
BATTERY	LITHIUM ION 60 V, 21 AH, And (33 Ah Battery Optional)
Range	70-80 Km Per charge for 22 Ah battery and 100-105 km for 33 Ah battery
Brake	FRONT : DISC & REAR BRAKE
Tyre Type	Tubeless
Console	Digital
CHARGER	4-6HRS ON STANDERED 5A CHARGER

---

PASSENGER CAPACITY	2 PERSON
RANGE (LOADED) (KM)* in Ideal Condition	70-80 km/charge and (100-105 km per charge optional)
MAX. SPEED (KM/H)	25KM/H
MIN. TURNING RADIUS(M)	1<=M
MAX. CLIMBING ABILITY (M)	UP TO 8%
BRAKING DISTANCE	2.8mm
MAX. LOADING WEIGHT (KGS)	150 KG

---

BRAKE SYSTEM	Front: DISC, Rear: Drum
MAX TORQUE	9 NM
FRONT SUSPENSION	Hydraulic Telescopic fork
REAR SUSPENSION	SPRING WITH HYDRAULIC CYLINDER SHOCK ABSORBER
Kerb Weight ( With Battery)	60kg
STARTING	Self-Start
WHEEL & TYRE	Tubeless /alloy

---

OVERALL DIMENSION (MM)	1801X685X1150 mm
WHEEL BASE (MM)	1320 mm

---

CHASSIS	Clad with steel metal
BODY	ABS/ Steel
WINDSHIELD	TOUGHENED LAMINATED SAFETY GLASS
FLOOR MAT	SKIPPROOF RUBBER
CROME FINISH STEEL GUARD	YES
DASHROOF	Speedometer : Digital; Fuel Gauge: Digital; Console: Digital;

---

LIGHT	Headlight : Halogen; Tail Light : LED; Turn Signal Lamp : LED
HORN	Yes
LOW BATTERY INDICATOR	Yes
DC TO DC CONVERTER	60 V TO 12 V
ELECTRICITY CONSUMPTION	1.2 UNITS
MOBILE CHARGER	YES
SMART CHARGE	1.5 HRS

---

GPS	YES (OPTIONAL)
Anti Theft Alarm	STANDARD
DISTANCE ONLINE LOCKING VIA MOBILE APP (INDIA FIRST)	Optional
BMS	YES
REGENERATIVE BREAKING SYSTEM	YES
CROME FINISH STEEL GUARD	Optional
MOBILE APP SUPPORT	Optional
BATTERY DOCKING SYSTEM	YES
Low Battery Indicator	YES
WARRANTY IF ANY	1 YEAR for motor and controller / 2 year for battery
ANDROID TOUCH SCREEN DISPLAY	CAN BE EMBEDDED
CAN BUS SUPPORT FOR ONLINE ANALYSIS (INDIA FIRST)	COMPATIIBLE
MAP LOCATION TRACKING (INDIA FIRST)	(Optional)
REMOTE CENTRAL LOCKING	YES
ALLOY WHEELS	YES / OPTIONAL
Carry Hook	Yes
